HLC-1XV01AAC(1P/25A/277VAC) Definite Purpose Contactor

Original price was: $14.50.Current price is: $13.00.

HLC-1XV01AAC(1P/25A/277VAC) Definite Purpose Contactor (Follow Defers To DP Contactor),Mainly Is Suitable For 50Hz Or 60Hz, When The AC-8a Use Category Fixed Working Voltage Is 240V Or 277V The Nominal Current Up To The 25A Electric Circuit, Is Suitable For The Starting And The Control Single-Phase Motor (Or Compressor) And Other Single-Phase Loads.Mainly Uses In The Domestic Electric Appliances Profession, Specially In Air Conditioning Profession,Conforms To IEC60947, UL508 and GB14048standard.

1000 in stock

*Applicable and Description

1. Applicable Scope

HLC-1XV01AAC(1P/25A/277VAC) Definite Purpose Contactor (Follow Defers To DP Contactor),Mainly Is Suitable For 50Hz Or 60Hz, When The AC-8a Use Category Fixed Working Voltage Is 240V Or 277V The Nominal Current Up To The 25A Electric Circuit, Is Suitable For The Starting And The Control Single-Phase Motor (Or Compressor) And Other Single-Phase Loads.Mainly Uses In The Domestic Electric Appliances Profession, Specially In Air Conditioning Profession,Conforms To IEC60947, UL508 and GB14048standard.

2.Type and Meaning
HLC1XV01AA C
Company CodeContactorPacking Y : Individual Box Pack    – : Factory Bulk PackPole: One Pole with ShuntCoil VoltageRating of currentTerminalWith Cover

*Product Explanation And Main Technical Parameter

TypeHLC-1XV01AAC(1P/25A/277VAC) Definite Purpose Contactor
StandardIEC60947UL508
Rating of CurrentIe 25AFLA: 25A
Resistive AmpsIth 35ARES: 35A
Rating of Contacts VoltageUe 240/277V240/277/480/600VAC
Rating of Insulation VoltageUi 660V600V
Rating of Coil VoltageUs 277VUs: 277VAC 50/60Hz
Mechanical Life1000,000 Cycle1000,000 Cycle
Electricity life100,000 Cycle250,000 Cycle
Product Explanation

1.Product Description

HLC-1XV01AAC Is Suitable To Exchanges 50 Or 60hz, Fixed Working Voltage To 240v or 277v, Fixed Operating Current To 30A Single-Phase Load Circuit Control,At Present, Widely Applies To The Single-Phase Mechanical Device Main Circuit As Well As The Single-Phase Air-Conditioner Compressor Control.

2 .The Regular Service Conditon And Installs The Condition
a. In The Surrounding Air Temperature The Limiting Value Is +65 , Gets
Down The Limiting Value Is -25
b. The Installation Site Elevation Does Not Surpass 2000m
c. The Air Pollution Rank Is 2 Levels
d. Installs The Category Is Ii ;
e. Installment Facing The Gradient Does Not Surpass ±5°
f. Not Remarkable Undulation, Impact And Vibration Place.

3 .Main Technical Parameter
a. Contactor Coil Picking Up In 75% ~ 110% Us Reliably
Working, Its Drop Out Voltage In 20% ~ 70%Us
b. Contactor Use Category: Ac-1Ac8a
c. Contactor In With 0.4m Place, Its Noise Below 40db.

4 . Installing Specification And Install Size

a. Installs The Way To Be Fixed For The Screw, Some Two Kinds Install The Size To Choose One Kind Of Size Fitting Surface And The Horizontal Plane Are The Vertical Shape Gradient Are Not Bigger Than ±5°

b. Before The Use Should Inspect The Power Terminal And The Contactor
Quick Connect Whether Inserts Arrives, Is Reliable, Avoids Creating
The Breakdown, Behind Check Off May Electrify Tries .



*Conforms To The Standard

Conforms To National Standard And International Standard1 Conforms To UL508, IEC60947, GB14048Standard
2 Approved By UL,CUL,TUV,CE,CCC,Safe Certification and ISO9001 System Certification(SGS)

CCC Certificate Number:  2005010309156761

UL Files Number: E251539

*Ordering Request

In Order To Guarantee You Purchase Right, Please Read The Specify Type Before Order.

Contactor Specification Model, Pole Number, Coil Control Voltage, Rating Of Operating Current, Wiring Way(Terminal), Whether With Cover ,The Packing Way, Etc


If You Request As Follows: Nominal Current: 25A, Working Voltage: 240/277V,480V,600V, Pole Number: One Pole Without Shunt, Coil Control Voltage:277V, Wiring Way: Quick Connect, Load Current: Single-Phase Motor Controls Or Heating Load, Packing: 50/Each Box (Factory Packing), With The Cover. Then You May Be Elect The Type : HLC-1XV01AAC

Lifts The Samples As Follows (Contains Derivation Type From This Model)

Rating of Current

Ie

PoleRating of Coil Control VoltageControl Motor Power
24VAC120VAC208/240VAC277VAC380/480VAC240VAC
25A1PHLC-1XQ01AACHLC-1XT01AACHLC-1XU01AACHLC-1XV01AACHLC-1XH01AAC1.5Kw
HLC Series Definite Purpose Contactor
Weight 0.24 kg
Dimensions 9 × 5.5 × 7 cm
