GDT-102 Delay on Make Timer

Universal voltage operation
Higher 1.5 amp power rating
Knob-adjustable time delays
Works with anticipator-type thermostats
One model replaces many in field

SKU: GDT-102 Category:

0.03 – 10 Minute solid state anti-cycle delay on make timer. (1.8-600 seconds)

Two Pin Delay-on-Make Timer

Compressor lockout/anti short cycle timer. Helps prevent scroll compressor reversal. Universal voltage operation
• Voltage 18-240 VAC
• Frequency 50-60 Hz
• 1.5 amp
• 15 amp inrush
• Fast response 16 ms

Conforms To The Standard
Conforms To National Standard And International Standard1 、Conforms To UL508 Standard
2 、Approved By UL,Safe Certification andISO9001 System Certification(SGS)
UL Files Number:  E251539
Ordering Request
DETAILS:
  • Universal voltage operation
  • Higher 1.5 amp power rating
  • Knob-adjustable time delays
  • Works with anticipator-type thermostats
  • One model replaces many in field
SPECIFICATIONS:
Input:
Voltage: 18-240 VAC
1.5 amp
15 amp inrush

Adjustable Time Delay:
.03-10 minutes (1.5-600 seconds)
WEIGHT/DIMENSIONS:
  • Weight: 0.1
  • Height: 1.25
  • Width: 2
  • Length: 2
Replaces:

A-1: EAC-701-ADJ

Diversified: AC-800

Gemline: 1C310, 1C213

Mars: 32019, 32391, 32367

Supco: TD69

Wagner/DiversiTech: ADM-1

ICM: ICM102
